AMM-520
Aidite Europe GmbH · source
Wet & Dry Milling machine
AMM-520 is a wet and dry integrated multi-functional milling machine, with a stable structure and a variety of fixture combinations, meeting different production needs.
Introduction
AMM-520 is a wet and dry integrated multi-functional milling machine, with a stable structure and a variety of fixture combinations, meeting different production needs.
Parameter
| Specification | Value |
|---|---|
| Number of axes | 5 Simultaneous Processing |
| Milling mode | Wet and dry |
| Millable material | Zirconia, PMMA, HPP, PEEK, Titanium disc, glass ceramic, denture, premill |
| Material thickness | 10-35mm (round disc) |
| Accessories | Work table, water cooler, water tank |
| Repeat positioning accuracy | ±5um |
| Linear drive system | Linear guide and lead screw |
| Rotary drive system | Harmonic reducer |
| Control system | Embedded CNC system and AC bus servo motor |
| Machine size | 590×730×820 (mm) |
| Machine weight | 180kg |
| Tool changer | 10 |
| Processing time | Single crown ≤15min, Premill ≤20min, Glass ceramic≤20min, full denture≤3h |
| Stroke | XYZ axis: 180X110x100 (mm), A-axis: ±361°, B-axis: -115°, +30° |
Spindle
- Power: AC 1500W
- Cooling: water cooling
- Speed: 60000rpm
- Chuck size: Φ6 mm
Input
- Power supply: single-phase AC 220V 50/60Hz Voltage
- Power: 2.2KW 10A
- Air pressure: 6Bar
Processing type
Denture, bitesplingt, snap on smile, surgical guide, partial framework, crown and bridge, veneer, inlay, post and core, screw-retained bridge (a separate nesting moudle needs to be added for implant case), custom abutment
Machinable Application
Product Information
| Manufacturer | Aidite Europe GmbH |
|---|---|
| Stroke | XYZ axis: 180X110x100 (mm), A-axis: ±361°, B-axis: -115°, +30° |
| Chuck Size | Φ6 mm |
| Accessories | Work table, water cooler, water tank |
| Air Pressure | 6Bar |
| Machine Size | 590×730×820 (mm) |
| Milling Mode | Wet and dry |
| Power supply | single-phase AC 220V 50/60Hz |
| Tool Changer | 10 |
| Spindle Power | AC 1500W |
| Spindle Speed | 60000rpm |
| Control System | Embedded CNC system and AC bus servo motor |
| Machine Weight | 180kg |
| Number Of Axes | 5 Simultaneous Processing |
| Processing Time | Single crown ≤15min, Premill ≤20min, Glass ceramic≤20min, full denture≤3h |
| Processing Type | Denture, bitesplingt, snap on smile, surgical guide, partial framework, crown and bridge, veneer, inlay, post and core, screw-retained bridge, custom abutment |
| Spindle Cooling | water cooling |
| Millable Material | Zirconia, PMMA, HPP, PEEK, Titanium disc, glass ceramic, denture, premill |
| Power Consumption | 2.2KW 10A |
| Material Thickness | 10-35mm (round disc) |
| Linear Drive System | Linear guide and lead screw |
| Rotary Drive System | Harmonic reducer |
| Repeat Positioning Accuracy | ±5um |
