Surgitime Titanium Seal
Bionnovation Biomedical · source
Non-resorbable membranes
These barriers have been widely used in guided bone regeneration (GBR) procedures in post-dental extraction sockets. In this context, one of the properties suggested for the GBR technique is that these barriers, when exposed to the oral environment, control or prevent the infiltration of connective and epithelial tissue cells, favoring the proliferation of bone cells inside the socket without bacterial infection.
Surgitime Titanium Seal
It is ideal for three-dimensional bone regeneration and was designed to be intentionally exposed during post-extraction alveolar sealing procedures, protecting the surgical wound against soft tissue invagination, which promotes resorption of the alveolar process. In this way, there is a statistically proven reduction in the rate of bone resorption. Because it is bioelectrically neutral thanks to electrochemical passivation, it contributes to uncomplicated new bone growth.
It is manufactured using commercially available titanium sheet. Pure Gr 1 In accordance with ASTM F67 and sterilized by Gamma Radiation.[25kGy]. The titanium is a safe material with an excellent track record in all surgical procedures.
Topographic analysis
The ultrastructural images revealed a rough surface, with no homogeneity in the surface structure.
Thickness ~0.04 mm
Surgical Procedures
Recommended and designed to stay intentionally Exposed in post-extraction alveolar sealing procedures, protecting the surgical wound against invagination of soft tissues, which promotes resorption of the alveolar process. In this way, there is a statistically proven reduction in the resorption process. It should be used by shaping the mesh, taking care to completely cover the operated area with a margin that varies from 2 to 4 mm.
They should not be reprocessed, and attention must be paid to sterilization deadlines and proper instrumentation. Regarding restrictions, it is up to the professional to carefully choose the location for their implantation; that is, they must carefully consider their use in an aesthetic setting.
Due to its malleability It can be cut to fit surgical sites and, being bioelectrically neutral thanks to electrochemical passivation, contributes to uncomplicated new bone growth.
Benefits
The Surgitime Titanium Seal has excellent biocompatibility. It's totally waterproof, and excludes the possibility of competition and invagination of soft tissues over bone grafts and defects.
Advantages: Manipulation
The Surgitime Titanium Seal is very flexible and can be used to cover periodontal defects or alveoli and generally does not require fixation; however, if necessary, it can be fixed with Bionnovation graft screws.
Time for removal
The required duration for the initiation of osteoconduction is at least 21 days and 14 days for use in cases of sealing fresh alveoli.
Features
- Greater tissue isolation
- Self-fixation [não requer parafusos de fixação]
- Total Occlusivity
- Easy Removal
- Extremely low biofilm retention
- Thickness ~0.04 mm
Product Information
| Manufacturer | Bionnovation Biomedical |
|---|---|
| Surface | Rough surface with no homogeneity in structure |
| Features | 100% waterproof, bioelectrically neutral, malleable, non-resorbable |
| Material | Pure Gr 1 titanium |
| Thickness | ~0.04 mm |
| Application | Guided bone regeneration (GBR), post-extraction alveolar sealing, periodontal defects |
| Certification | ASTM F67 |
| Sterilization | Gamma Radiation [25kGy] |
| Coverage Margin | 2 to 4 mm |
| Recommended Exposure Duration | At least 21 days for osteoconduction initiation; 14 days for fresh alveoli sealing |
